M/B Form Factor
Micro-ATX (M-ATX) / Mini-ITX
Drive bays
2 x 2.5" Dedicated SSD Mounts2 x 2.5" / 3.5" Hybrid Combo Drive Trays
Max CPU cooler height
Up to 160 mm
Max VGA card length
Up to 300 mm
Cooling System
Includes 4 x 120mm Auto-RGB fans pre-mounted out of the box (3 x front intake fans and 1 x rear exhaust fan displaying a fixed rainbow lighting preset). Includes an internal 1-to-6 SATA-powered fan control hub to accommodate your cooling expansions. (Supports up to 6 fans total):Front: 3 x 120 mm or 2 x 140 mm fans.Top: 2 x 120 mm fans.Rear: 1 x 120 mm fan.Liquid Cooling Radiator Support:Top: 120 / 240 mm liquid AIO water-cooling systems.Rear: 120 mm radiator loops.(Note: Front-mounted radiators are not natively supported due to the compact depth profile of the chassis)
Material of Chassis
Premium SPCC Steel Structure + 3mm Tempered Glass Left Side Panel
I/O panel
1 x USB 3.2 Gen 1 (5Gbps) Type-A, 2 x USB 2.0 Type-A, 1 x HD Audio Out, 1 x Mic In, LED On/Off Button, Power & Reset Buttons
Product Size
(DxWxH): 388 x 200 x 423 mm
Packing Size
(DxWxH): 388 x 200 x 423 mm
NW
4.40 kg (9.70 lbs)
GW
5.23 kg (11.53 lbs)
