M/B Form Factor
ATX / Micro-ATX (M-ATX) / Mini-ITX
Drive bays
3.5" HDD Bays: 2 internal slots2.5" SSD Bays: 1 internal slot5.25" ODD Bays: None (No support for legacy external optical CD/DVD drives)
Max CPU cooler height
Up to 150 mm
Max VGA card length
Up to 310 mm
Cooling System
Includes 3 x 120mm RGB cooling fans out of the box (typically pre-mounted as 2 x front intakes and 1 x rear exhaust). (Supports up to 6 fans total):Front: 3 x 120 mm or 2 x 140 mm fans.Top: 2 x 120 mm fans.Rear: 1 x 120 mm fan.Liquid Cooling Radiator Support:Front: 120 / 240 mm liquid AIO water-cooling radiator kits.Top: 120 / 240 mm liquid AIO radiator loops.
Material of Chassis
Convey Metal Structure + Tempered Glass Side Window
I/O panel
1 x USB 3.0, 2 x USB 2.0, HD Audio, Microphone Jack
Product Size
375 × 200 × 452 mm
Packing Size
(LxWxH): ~495 x 245 x 435 mm (Bare product dimensions measure 375 x 200 x 452 mm)
NW
~4.30 kg (Standalone chassis structural weight built on standard entry-grade steel thickness)
GW
~5.30 kg (Total estimated weight packaged inside its retail shipping box)
