M/B Form Factor
Micro-ATX (M-ATX) / Mini-ITX
Drive bays
2 x 3.5" HDD Bays1 x 2.5" SSD Bay5.25" ODD Bays: None (No support for legacy external optical drives)
Max CPU cooler height
Up to 165 mm
Max VGA card length
Up to 340 mm (Easily fits larger triple-fan graphics cards)
Cooling System
Includes 3 x 120mm ARGB cooling fans pre-configured out of the box (2 x reverse-blade side panel intake fans and 1 x standard rear panel exhaust fan). Fan Mounting Options:Side: 2 x 120 mm fans (Pre-installed).Top: 2 x 120 mm fans (Optional).Rear: 1 x 120 mm fan (Pre-installed) Liquid Cooling Radiator Support:Top / Side: 120 / 240 mm liquid AIO water-cooling radiator kits.Rear: 120 mm radiator loops
Material of Chassis
0.6mm SPCC Steel Body + 4mm Tempered Glass Panels + White Structural Coating
I/O panel
1 x USB 3.0, 2 x USB 2.0, 1 x HD Audio Jack, 1 x Microphone Jack
Product Size
353 × 210 × 450 mm
Packing Size
(LxWxH): 512 × 279 × 425 mm (Bare case dimensions measure 353 x 210 x 450 mm)
NW
~4.50 kg (Standalone chassis structural weight with heavy dual tempered glass panes)
GW
~5.50 kg (Total estimated weight packaged inside its retail box with standard shipping protective foam sheets)
