M/B Form Factor
Micro-ATX (mATX) and Mini-ITX
Drive bays
Option A: 1x 3.5" HDD + 2x 2.5" SSD Option B: 2x 3.5" HDD + 1x 2.5" SSD
Max CPU cooler height
Up to 160 mm
Max VGA card length
Up to 280 mm
Cooling System
Front: 3x 120 mm fansTop: 2x 120 mm fansBottom (on PSU Shroud): 2x 120 mm fans Rear: 1x 120 mm fan
Material of Chassis
Steel chassis, ABS plastic front panel, and a Tempered Glass side door
I/O Panel
1x USB 3.02x USB 2.01x HD Audio I/O (Headphone + Microphone jacks)
Product Size
355 x 200 x 390 mm
Packing Size
440 x 240 x 415 mm
NW
~3.2 kg (the standalone case weight with the tempered glass panel attached).
GW
~3.9 kg – 4.0 kg (total weight including the outer cardboard box, protective foam inserts, manual, and included mounting accessories)
